Drive Axle for Forklifts

Drive Axle for Forklift - A lift truck drive axle is actually a piece of equipment that is elastically connected to a vehicle frame utilizing a lift mast. The lift mast is connected to the drive axle and is capable of being inclined round the axial centerline of the drive axle. This is done by no less than one tilting cylinder. Frontward bearing parts together with rear bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H45, H35 and H40 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the framework of the forklift by many different bearings. The drive axle consists of tubular axle body along with extension arms attached to it and extend rearwards. This particular kind of drive axle is elastically affixed to the vehicle framework utilizing rear bearing elements on the extension arms along with frontward bearing devices located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the forklift from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle on this model of lift truck are sustained by the extension arms through the back bearing components on the frame. The forces created by the load being carried and the lift mast are transmitted into the floor or roadway by the vehicle framework through the front bearing parts of the drive axle. It is essential to be certain the components of the drive axle are configured in a rigid enough manner so as to maintain stability of the forklift truck. The bearing elements could reduce minor bumps or road surface irregularities throughout travel to a limited extent and give a bit smoother function.
